Graphic Engine
AMD Radeon RX 5700
Bus Standard
PCI Express 4.0
OpenGL
OpenGL®4.6
Video Memory
8GB GDDR6
Engine Clock
OC Mode : P Mode : Up to 1720 MHz (Game clock), Up to 1750 MHz (Boost clock)
Gaming Mode : P Mode : Up to 1675 MHz (Game clock), Up to 1750 MHz (Boost clock)
Gaming Mode : P Mode : Up to 1675 MHz (Game clock), Up to 1750 MHz (Boost clock)
Stream Processors
2304
Memory Speed
14 Gbps
Memory Interface
192-bit
Resolution
7680×4320
Interface
Yes x 1 (Native HDMI 2.0b)
Yes x 3 (Native DisplayPort 1.4)
HDCP Support Yes (2.3)
Yes x 3 (Native DisplayPort 1.4)
HDCP Support Yes (2.3)
Maximum Display Support
6
NVlink/ Crossfire Support
Yes ***
Software
ASUS GPU Tweak II & Drivers: please download all software from the support site.
Dimensions
10.6 ” x 5 ” x 2.1 ” Inch
26.9 x 12.5 x 5.4 Centimeter
26.9 x 12.5 x 5.4 Centimeter
Recommended PSU
600W
Power Connectors
1 x 6-pin, 1 x 8-pin
Slot
2.7 Slot
Note
* Crossfire Support – Yes for DirecX® 12 and Vulkan®
* ‘Game Clock’ is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
* ‘Boost Clock’ is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
* ‘Game Clock’ is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
* ‘Boost Clock’ is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
