- Diagonal Viewing Size
47.02 cm (18.5 inches)Horizontal Viewing Size
409.8 mm (16.13 inches)Vertical Viewing Size
230.4 mm (9.07 inches)Maximum Preset Resolution
1366 x 768 at 60HzAspect Ratio
0.30 mm x 0.30 mmPixel Per Inch (PPI)
200 cd/m² (typical)Color Support
Color gamut (typical): 83% (CIE1976) 72% (CIE1931)
Color depth: 16.7 MillionContrast Ratio
600:1 (typical)Viewing Angle
5 ms typical (Normal) (gray to gray)
TN (Twisted Nematic)
Display Screen Coating
ComfortView with Flicker-free screen
Dell Display Manager Compatibility
Remote Asset Management
Yes, via Dell Command I Monitor
AC511 – usb powered via PC
AE515 Skype for Business Certified
Tilt Only (-5° to 21°)
Security lock slot (cable lock sold separately)
1 X VGA
1 X DisplayPort 1.2HDCP Support
DisplayPort HDCP 1.2
Dimensions & Weight
- Dimensions (with stand)
359.60 mm (14.16 inches)
445.4 mm (17.54 inches)
171.0 mm (6.73 inches)Weight (with stand)
Weight (panel only – for VESA mount/ no cables)
2.19 kg (4.83 lbs)
Weight (monitor + cables)
2.93 kg (6.46 lbs)
Weight (with packaging)
3.92 kg (8.66 lbs)
- AC input voltage/frequency/current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 0.6 A (typical)Power Consumption (Operational)
10W (typ) . 14W (Max). 9.51W (Energy Star)Power Consumption Stand by/Sleep
Less than 0.3W
- Standard Service Plan
3 Years Advanced Exchange Service and Limited Hardware WarrantyOptional Service Plan
In The Box
Monitor with standCables
1 X DP Cable (DP to DP)
1 X VGA Cable (EMEA and Japan only)
1 X VESA screw coverDocumentation
Quick Setup Guide
Safety and regulatory information
ENERGY STAR®, EPEAT® registered where applicable, TCO Certified Display
Maximize your workspace: A thin profile1 and improved cable management create a smaller footprint, lending itself to a clean, uncluttered desk.
Enhanced views: The 1366×768 resolution is ideal for everyday tasks, while ComfortView is ready for extended viewing periods. It reduces up to 60% of harmful blue light emissions.2
Versatile connections: Our E Series monitors accommodate legacy and non-legacy systems with convenient connectivity options like VGA and DP ports. Your workspace will be completely customized to your needs.
Adapts to your needs: Make your workspace your own with VESA-compatible mounts and stands.
Productive at every level: Dell Display Manager’s (DDM) Easy Arrange feature lets you quickly tile and view your applications side by side across one or more connected screens for multitasking efficiency. And with the improved DDM, you’ll get even more preset layouts.
Seamless transitions: The auto-restore feature remembers where you left off, so applications will go back to where you left them, even after you’ve unplugged.
The key to convenience: Shortcut keys can save you even more time, letting you easily configure your display management settings so you can get to work faster.
More ways to manage: Asset management reports allow IT managers to quickly capture and track monitor information as well as configure multiple monitors at once through a single setup.
Guaranteed green: Compliant with the latest Energy Star® standards, the E Series monitors meet stringent energy efficiency requirements while in sleep, on and off modes. They’re also TCO-certified.3
Energy reducing: Save energy with PowerNap, a feature that dims or puts the monitor to sleep when not in use.
Clean disposal: Composting or recycling the packaging is easy since it’s made with at least 25% of recycled cardboard.4
1. Power Port | 2. DP Port 1.2 | 3. VGA PortCables Included
1 x Power cable
1 x DisplayPort cable
