| Brand | GIGABYTE |
|---|---|
| Model | GP-P750GM |
| Type | ATX 12V v2.31 |
|---|---|
| Maximum Power | 750W |
| Fans | 120mm Hydraulic Bearing (HYB)Fan |
| PFC | Active |
| Main Connector | 20+4Pin |
| PCI-Express Connector | 4 x 6+2-Pin |
| SATA Power Connector | 8 |
| Modular | Full Modular |
| Power Good Signal | 100-500ms |
| Hold-up Time | 16ms min. |
| Efficiency | 90% at typical load |
| Energy-Efficient | 80 PLUS GOLD Certified |
| Over Voltage Protection | Yes |
| Protection | OVP / OPP / SCP / UVP / OCP / OTP |
| Input Voltage | 100 – 240 V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 12 – 6 A |
| Output | +3.3V@20A, +5V@20A, +12V@61A, [email protected], +5VSB@3A |
| MTBF | >100,000 Hours |
| Approvals | BSMI / CE / CCC / FCC / TUV / RCM / CB / EAC / KCC / UL |
| Dimensions | 3.39″ x 5.91″ x 5.51″ |
| Max PSU Length | 140 mm |
| Connectors | 1 x ATX/MB 20+4 Pin 2 x EPS/ATX 12V 4+4pin 4 x PCI-e 6+2 pin 8 x SATA 5 pin 3 x Peripheral 4-pin 1 x Floppy 4-pin |
|---|---|
