Essentials
- Product Collection Intel® Pentium® Processor G Series
- Code Name Products formerly Ivy Bridge
- Vertical Segment Desktop
- Processor Number G2020
- Lithography 22 nm
- Recommended Customer Price$64.00
CPU Specifications
- Total Cores 2
- Total Threads 2
- Processor Base Frequency 2.90 GHz
- Cache 3 MB Intel® Smart Cache
- Bus Speed 5 GT/s
- TDP 55 W
Supplemental Information
- Marketing Status Discontinued
- Launch Date Q1’13
- Servicing Status End of Servicing Lifetime
- End of Servicing Updates Date Tuesday, December 31, 2019
- Embedded Options Available No
- Datasheet View now
Memory Specifications
- Max Memory Size (dependent on memory type) 32 GB
- Memory Types DDR3 1333
- Max # of Memory Channels 2
- Max Memory Bandwidth 21 GB/s
- ECC Memory Supported ‡ Yes
Processor Graphics
- Processor Graphics ‡ Intel® HD Graphics for 3rd Generation Intel® Processors
- Graphics Base Frequency 650 MHz
- Graphics Max Dynamic Frequency 1.05 GHz
- Intel® Quick Sync Video No
- Intel® InTru™ 3D Technology No
- Intel® Clear Video HD Technology No
- # of Displays Supported ‡ 3
Expansion Options
- PCI Express Revision 2.0
- PCI Express Configurations ‡ up to 1×16, 2×8, 1×8 & 2×4
Package Specifications
- Sockets Supported FCLGA1155
- Max CPU Configuration 1
- Thermal Solution Specification 2011C
- Package Size 37.5mm x 37.5mm
Advanced Technologies
- Intel® Optane™ Memory Supported ‡ No
- Intel® Turbo Boost Technology ‡ No
- Intel® Hyper-Threading Technology ‡ No
- Intel® 64 ‡ Yes
- Instruction Set 64-bit
- Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2
- Intel® My WiFi Technology No
- Idle States Yes
- Enhanced Intel SpeedStep® Technology Yes
- Thermal Monitoring Technologies Yes
Security & Reliability
Give Feedback
All information provided is subject to change at any time, without notice. Intel may make changes to manufacturing life cycle, specifications, and product descriptions at any time, without notice. The information herein is provided “as-is” and Intel does not make any representations or warranties whatsoever regarding accuracy of the information, nor on the product features, availability, functionality, or compatibility of the products listed. Please contact system vendor for more information on specific products or systems.
Intel classifications are for general, educational and planning purposes only and consist of Export Control Classification Numbers (ECCN) and Harmonized Tariff Schedule (HTS) numbers. Any use made of Intel classifications are without recourse to Intel and shall not be construed as a representation or warranty regarding the proper ECCN or HTS. Your company as an importer and/or exporter is responsible for determining the correct classification of your transaction.
Refer to Datasheet for formal definitions of product properties and features.
‡ This feature may not be available on all computing systems. Please check with the system vendor to determine if your system delivers this feature, or reference the system specifications (motherboard, processor, chipset, power supply, HDD, graphics controller, memory, BIOS, drivers, virtual machine monitor-VMM, platform software, and/or operating system) for feature compatibility. Functionality, performance, and other benefits of this feature may vary depending on system configuration.
Some products can support AES New Instructions with a Processor Configuration update, in particular, i7-2630QM/i7-2635QM, i7-2670QM/i7-2675QM, i5-2430M/i5-2435M, i5-2410M/i5-2415M. Please contact OEM for the BIOS that includes the latest Processor configuration update.
“Announced” SKUs are not yet available. Please refer to the Launch Date for market availability.
Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each processor family, not across different processor families. See http://www.intel.com/content/www/us/en/processors/processor-numbers.html for details.
See http://www.intel.com/content/www/us/en/architecture-and-technology/hyper-threading/hyper-threading-technology.html?wapkw=hyper+threading for more information including details on which processors support Intel® HT Technology.
Max Turbo Frequency refers to the maximum single-core processor frequency that can be achieved with Intel® Turbo Boost Technology. See www.intel.com/technology/turboboost/ for more information and applicability of this technology.
Processors that support 64-bit computing on Intel® architecture require an Intel 64 architecture-enabled BIOS.
System and Maximum TDP is based on worst case scenarios. Actual TDP may be lower if not all I/Os for chipsets are used.
Intel® Iris® Xe Graphics only: to use the Intel® Iris® Xe brand, the system must be populated with 128-bit (dual channel) memory. Otherwise, use the Intel® UHD brand.
