Chassis Specifications
| Dimension (H*W*D) | 465 x 215 x 400mm (18.3 x 8.46 x 15.75 inch) |
| Color | Exterior & Interior : Black / White |
| Material | SPCC |
| Side Panel | 4mm Tempered Glass*1 (Left Side) |
| Form Factor | Mini-ITX, Micro-ATX, ATX |
| 3.5″ HDD/HDD tray | 2+1 (Combo 3.5” + 2.5”) |
| 2.5″ HDD/SSD tray | 2+1 (Combo 3.5” + 2.5”) |
| I/O Port | x2 USB 3.0, x1 Hybrid Audio Port, x1 LED Control Button |
Fan Included
| Front | 1 x XPG VENTO 120 |
| Rear | 1 x XPG VENTO 120 ARGB |
Fan Support
| Front | 120mm x3 , 140mm x2 |
| Top | 120mm x2 , 140mm x2 |
| Rear | 120mm x1 |
Radiator Support
| Front | 360 / 280 / 240mm x1 |
| Top | 280 / 240 / 120mm x1 |
| Rear | 120mm x1 |
Clearance
| CPU Cooler Height Limitation | 165mm |
| Graphic Card Length Limitation | 350mm |
| PSU Length Limitation | 160mm
PSU PROBE 600W *80 Plus Bronze Certified. *Single Rail +12V design delivers 46A *Premium 100% Japanese Capacitors with 105c tolerance *ATX 24pin Connector x 1 *EPS Connector x 1 *SATA Connector x 5 + Molex Connector x2 *PCI-E Connector (6+2pin) x 2 *12cm sleeve bearing fan *OVP/OPP/SCP/UVP/OTP |
