ASROCK B460 Steel Legend
- Supports 10th Gen Intel® Core™ Processors (Socket 1200)
- 9 Phase Dr.MOS Power Design
- Supports DDR4 2933MHz
- 2 PCIe 3.0 x16, 2 PCIe 3.0 x1, 1 M.2 (Key E) For WiFi
- AMD CrossFireX™
- Graphics Output Options: HDMI, DisplayPort
- 7.1 CH HD Audio (Realtek ALC1200 Audio Codec), Nahimic Audio
- 6 SATA3, 1 Ultra M.2 (PCIe Gen3 x4 & SATA3), 1 Ultra M.2 (PCIe Gen3 x4)
- 7 x USB 3.2 Gen1 (1 Rear Type-C, 3 Rear Type-A, 2 Front, 1 Front Type-C)
- Dragon 2.5 Gigabit LAN
- ASRock Polychrome SYNC
Out of stock
Get Endless Performance Possibilities with Steel Style
Base Frequency Boost (BFB) Technology
Who ever said that only K series CPUs and the Z-family platform are capable of being performed with maximum power. Via ASRock BFB (Base Frequency Boost) Technology, users may install their non K series CPUs to ASRock’s selected 400 series motherboards and enjoy the base frequency boost with the hidden power of processors immediately.
While ASRock BFB breathes life into non K series CPUs, the boost frequency currently still depends on the cooling system applied on your rig.
Premium 60A Power Choke
RULE YOUR OWN LIGHTING WAY – POLYCHROME RGB
*The RGB LED header supports standard 5050 RGB LED strip (12V/G/R/B), with a maximum power rating of 3A (12V) and length within 2 meters.
Dragon 2.5 Gb/s LAN
A SOLID M.2-SOLUTION PERFORMER
Dual M.2 For SSD
PCI-E STEEL SLOT
Front USB 3.2 Gen1 Type-C
M.2 (KEY E) For WiFi
Besides the onboard LAN port, users may also choose 802.11ac wireless connections by M.2 (Key E) slot.
Post Status Checker
Intel® Optane™ Memory Ready
Gold Audio Jacks
Water Pump Header
Full Spike Protection
Live Update & APP Shop
ASRock Live Update & APP Shop is designed for your convenience. We provide various apps and support software for users to download. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.
The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
