- Specifications
-
- Mfr Part Number: BP-WG650UMAG-7FM
- Features:
- High Efficiency Layout
- Intelligent Fan-Curve
- Industrial Quality Fan
- Ultra Efficient
- Environmental Friendly
- Dedicated Quad Rails
- DC-to-DC Circuit
- Maximum Power on 12V Rails
- User Friendly Design
- Modular Cables
- High Performance Cables
- 100% Industrial Japanese Capacitors
- Solid Capacitors
- Support up to Industrial Servers
- LLC Resonant Topology
- Industrial Level Protection
- Maximum Power: 650 W
- Input:
- Voltage: 100 – 240 V AC
- Current: 10 A
- Frequency: 47 – 63 Hz
- Type: ATX 12V V2.4
- APFC PF Value: > 0.99
- MTBF: > 100,000hrs
- Efficiency: 80Plus Gold, up to 92%
- Fan: 1x 135mm Fan
- Output: +3.3V @ 20A, +5V @ 20A, +12V MBPH @ 25A, +12V CPU @ 25A, +12V VGA1 @ 30A, +12V VGA2 @ 30A, -12V @ 0.3A, +5VSB @ 2.5A
- Connectors: 1x 20+4pin Main Power Connector, 1x 4+4pin CPU Power Connector, 4x 6+2pin VGA Connectors, 8x SATA Connectors, 4x Molex Connectors
- Protection: OPP/ OVP/ OCP/ UVP/ SCP/ NLO/ OTP/ SIP
- Safety Approvals: cTUVus, TUV, CB, CE, FCC, BSMI
- Dimensions (WxDxH): 150.0 x 160.0 x 86.0 mm
