CPU Specifications
- Total Cores12
- # of performance cores 8
- # of Efficient-cores4
- Total Threads 20
- Max Turbo Frequency5.00 GHz
- Intel® Turbo Boost Max Technology 3.0 Frequency ‡5.00 GHz
- Performance-core Max Turbo Frequency of 4.90 GHz
- Efficient-core Max Turbo Frequency 3.80GHz
- Performance-core Base Frequency3.60 GHz
- Efficient-core Base Frequency 2.70GHz
- Cache25 MB Intel® Smart Cache
- Total L2 Cache12 MB
- Processor Base Power125 W
- Maximum Turbo Power190 W
Supplemental Information
Memory Specifications
- Max Memory Size (depending on memory type) 128 GB
- Memory TypesUp to DDR5 4800 MT/s
Up to DDR4 3200 MT/s - Max # of Memory Channels 2
- Max Memory Bandwidth76.8 GB/s
Processor Graphics
- Processor Graphics ‡Intel® UHD Graphics 770
- Graphics Base Frequency300 MHz
- Graphics Max Dynamic Frequency1.50 GHz
- Graphics OutputeDP 1.4b, DP 1.4a, HDMI 2.1
- Execution Units32
- Max Resolution (HDMI)‡4096 x 2160 @ 60Hz
- Max Resolution (DP)‡7680 x 4320 @ 60Hz
- Max Resolution (eDP – Integrated Flat Panel)‡5120 x 3200 @ 120Hz
- DirectX* Support12
- OpenGL* Support 4.5
- Multi-Format Codec Engines2
- Intel® Quick Sync VideoYes
- Intel® Clear Video HD TechnologyYes
- # of Displays Supported ‡4
- Device ID0x4680
- OpenCL* Support2.1
Expansion Options
- Direct Media Interface (DMI) Revision4.0
- Max # of DMI Lanes8
- Scalability1S Only
- PCI Express Revision5.0 and 4.0
- PCI Express Configurations ‡ Up to 1×16+4, 2×8+4
- Max # of PCI Express Lanes 20
Package Specifications
- Sockets Supported FCLGA1700
- Max CPU Configuration1
- Thermal Solution Specification PCG 2020A
- TJUNCTION100°C
- Package Size : 45.0 mm x 37.5 mm
Advanced Technologies
- Intel® Gaussian & Neural Accelerator 3.0
- Intel® Thread DirectorYes
- Intel® Deep Learning Boost (Intel® DL Boost) Yes
- Intel® Optane™ Memory Supported ‡ Yes
- Intel® Speed Shift Technology Yes
- Intel® Turbo Boost Max Technology 3.0 ‡ Yes
- Intel® Turbo Boost Technology ‡ 2.0
- Intel® Hyper-Threading Technology ‡Yes
- Intel® Virtualization Technology (VT-x) ‡Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
- Intel® 64 ‡Yes
- Instruction Set 64-bit
- Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2
- Idle StatesYes
- Enhanced Intel SpeedStep® Technology Yes
- Thermal Monitoring TechnologiesYes
- Intel® Volume Management Device (VMD)Yes
