AMD RDNA™ 3 Architecture
24GB of GDDR6 memory
AMD Radiance Display™ Engine
DisplayPort™ 2.1
AMD FidelityFX™ Super Resolution
AMD Radeon Super Resolution
4K and Beyond
Digital Power Design
Ultra High Performance Conductive Polymer Aluminum Capacitor
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Graphics Card Supporter
Bundled with a graphics card supporter to keep the graphics card in place on the PCIe Slot.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
AMD RDNA™ 3
Specifications
GPU
5nm GPU
AMD RDNA™ 3 Architecture
Engine Clock
- Boost Clock: Up to 2525 MHz
- Game Clock: Up to 2330 MHz
Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors
Compute Units
Infinity Cache
Ray Accelerators
Memory Size/Bus
Memory Clock
Displays
Resolution
- HDMI™: 7680×4320
- DisplayPort 2.1: 7680×4320
Interface
PCI-Express 4.0 x16
Output
- 2x HDMI
- 2x DisplayPort
BIOS Support
- UEFI
Game Index
4K
Sapphire Features
- Premium Digital Power Design
- Ultra High Performance Conductive Polymer Aluminum Capacitors
- Fuse Protection
- High TG Copper PCB
- Optimized Composite Heatpipe
- Tri-X Technology
- Intelligent Fan Control
- Precision Fan Control
- Metal Backplate
- Two-Ball Bearing Fans
- Angular Velocity Fan Blade
- TriXX Supported
- TriXX Boost
- Graphics Card Supporter
AMD Features
- AMD RDNA™ 3 Gaming Architecture
- 96 AMD RDNA™ 3 Compute Units (with RT+AI Accelerators)
- 96MB AMD Infinity Cache™ technology
- DisplayPort™ 2.1
- AMD Radiance Display™ Engine
- AMD Radeon™ Boost technology*
- AMD Radeon™ Anti-Lag* technology*
- 24GB GDDR6 on 384-Bit Memory Bus
- PCI® Express 4.0 ready
- AMD FidelityFX™ technologies*
- AMD FidelityFX™ Super Resolution technology*
- Microsoft® DirectX® 12 Ultimate
- Microsoft® DirectStorage
- Vulkan® Optimized
- AMD smart technologies*
- AMD Software: Adrenalin Edition™ application
- AMD Noise Suppression*
- AMD Privacy View*
- AMD Radeon™ Super Resolution technology*
- AMD Link*
- AMD Freesync™ technology
Cooling
3 Fans
Form Factor
Dimension: 313(L)X 133.75(W)X 52.67 (H)mm
Power Consumption
370W Total Board Power
OS
Linux®, Windows® 10, and Windows 11. 64-bit operating system required
System Requirement
- Minimum 800 Watt Power Supply
- 3 x 8-pin Power Connector.
- PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
- Minimum 8GB of system memory. 16GB recommended.
- Specifications provided here are for guidance only. Please check with your regional distributor or dealer for latest specifications.
- Colors of PCB or other components may differ from those illustrated.
- SAPPHIRE reserves the right to update or revise specifications without prior notice.
- All trademarks and logos are acknowledged as the property of their respective holders.
*The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
